TANDEM FENDER

Technical Specifications

Size Guide

BUY OR CUSTOMIZE NOW

The Fendertex Tandem Fender dual tube design prevents it from rolling on itself and protects a larger area than other shaped fenders. The tandem fender can be used in multiple applications:

  • For tenders to tie to the main yacht
  • Attached to swim platforms to "Med tie" or stern tie to a dock
  • For sailboats at the widest point of the vessel

The fender is knitted using a patented high-tech polyester textile and inflated with an ultrasonically welded polyurethane bladder. The fender offers high abrasion resistance and high compression strength, built with 316 stainless steel d-rings located at the top. Fendertex Tandem Fenders are ultralightweight, easy to handle, and can be deflated and rolled to minimize storage space.

All Fendertex Tandem Fender textiles are dyed in mass, making them highly resistant to UV degradation and color fading. In addition, the patented salt-resistant material and knitting technique was designed for the megayacht market to limit abrasion on the hull and paint. As a result, Fendertex Fenders material will leave no marks on the outside of the hull.

* Custom colors are available (6-10 week lead time for custom colors).

Fendertex Colors

TECHNICAL SPECIFICATIONS

Details of a Fendertex Tandem Fender
FENDER DETAILS
  1. 316 stainless steel D-ring.
  2. Suspension strap sewn into a cross for added strength.
  3. Retention strap to prevent deformation of the collar during compression.
  4. Highly elastic inflatable inner bladder. Water can be added to act as ballast for the fender.
  5. A technical textile made from polyester with high abrasion resistance. Does not absorb salt, thus avoiding micro scratches on the hull. Easy to clean with water or in a standard washing machine.
TEMPERATURE RESISTANCE
Textile Cover: 284°F (140°C) static / 320°F (160°C) dynamic
Inner Bladder: 293°F (145°C) static / 257°F (125°C) dynamic

SIZE GUIDE

Boat Length Tandem Fender Model Dimensions
30 - 43 feet
(9 - 17 meters)
T73 Depth: 5"
Height: 27.5"
Width: 10"
43 - 52 feet
(16 - 19 meters)
T84 Depth: 6"
Height: 31.5"
Width: 12"
52 - 62 feet
(19 - 30 meters)
T104 Depth: 6.5"
Height: 39.5"
Width: 13.5"
62 - 98 feet
(16 - 19 meters)
T124 Depth: 7"
Height: 47"
Width: 14.5"
98 - 131 feet
(30 - 40 meters)
T145 Depth: 9.5"
Height: 55"
Width: 19.5"
131 - 180 feet
(40 - 55 meters)
T175 Depth: 11"
Height: 67"
Width: 22"
180 - 230 feet
(55 - 70 meters)
T207 Depth: 13.5"
Height: 79"
Width: 27.5"
230 - 328 feet
(70 - 100 meters)
T248 Depth: 18.5"
Height: 94.5"
Width: 37.5"
Custom Fendertex Fender

CUSTOMIZATION

Fendertex Fenders are highly customizable. You can select from the many options, such as fender cover, covered D-rings, whip, etc. Each of these components can be done in any of the ten colors.

BUILD YOUR FENDER
